Hydrocodone Bitartrate and Homatropine Methylbromide Tablets

This article is compiled based on the United States Pharmacopeia (USP) – 2025 Edition

Issued and maintained by the United States Pharmacopeial Convention (USP)

DOWNLOAD PDF HERE

1 DEFINITION

Hydrocodone Bitartrate and Homatropine Methylbromide Tablets contain NLT 90.0% and NMT 110.0% of the labeled amounts of hydrocodone bitartrate disesquihydrate (C₁₈H₂₁NO₃.C₄H₆O₆. 2½H₂O) and homatropine methylbromide (C₁₇H₂₄BrNO₃).

[Note—Use of silanized autosampler vials such as dimethyldichlorosilane vials¹ is required for Dissolution Test 1 and Test 2, the Limit tests, and the Assay to prevent drug degradation.]

2 IDENTIFICATION

The UV absorption spectra of the hydrocodone bitartrate and homatropine methylbromide peaks of the Sample solution and those of the Standard solution exhibit maxima and minima at the same wavelengths, as obtained in the Assay.

The retention times of the hydrocodone bitartrate and homatropine methylbromide peaks of the Sample solution correspond to those of the Standard solution, as obtained in the Assay.

3 ASSAY

Change to read: Procedure

Buffer: 0.005 M dibasic potassium phosphate. Adjust with phosphoric acid to a pH of 6.4 ± 0.1  . Mobile phase: Acetonitrile and Buffer (30:170)

Standard solution: 0.2 mg/mL of USP Hydrocodone Bitartrate RS and 0.06 mg/mL of USP Homatropine Methylbromide RS in Mobile phase Sample solution: Nominally 0.2 mg/mL of hydrocodone bitartrate and 0.06 mg/mL of homatropine methylbromide prepared as follows. Transfer a portion of fine powder from NLT 20 Tablets to a suitable volumetric flask. Add 60% of the nal volume of Mobile phase, sonicate for 15 min, and then shake with a wrist-action shaker for an additional 15 min. Dilute with Mobile phase to volume. Pass the solution through a suitable filter of 0.45-µm pore size.

Chromatographic system

Mode: LC

Detectors

Assay: UV 230 nm

Identification test A: Diode array, UV 200–400 nm

Column: 4.6-mm × 25-cm; 5-µm packing L7

Flow rate: 1.5 mL/min

Injection volume: 10 µL

System suitability

Sample: Standard solution

[Note—The relative retention times for homatropine methylbromide and hydrocodone bitartrate are about 0.44 and 1.0, respectively.] Suitability requirements

Resolution: NLT 2.5 between hydrocodone bitartrate and homatropine methylbromide

Relative standard deviation: NMT 3.0% for each analyte

Analysis

Samples: Standard solution and Sample solution

Calculate the percentage of the labeled amount of homatropine methylbromide (C₁₇H₂₄BrNO₃) in the portion of Tablets taken:

Result = (r_U/r_S) × (C_S/C_U) × 100

r_U = peak response of homatropine methylbromide from the Sample solution

r_S = peak response of homatropine methylbromide from the Standard solution

C_S = concentration of USP Homatropine Methylbromide RS in the Standard solution (mg/mL)

C_U = nominal concentration of homatropine methylbromide in the Sample solution (mg/mL)

Calculate the percentage of the labeled amount of hydrocodone bitartrate disesquihydrate (C₁₈H₂₁NO₃.C₄H₆O₆. 2½H₂O) in the portion of 18

Tablets taken:

Result = (r_U /r_S) × (C_S/C_U ) × (M_r1/M_r2) × 100

r_U = peak response of hydrocodone bitartrate from the Sample solution

r_S = peak response of hydrocodone bitartrate from the Standard solution

C_S = concentration of USP Hydrocodone Bitartrate RS in the Standard solution (mg/mL)

C_U = nominal concentration of hydrocodone bitartrate in the Sample solution (mg/mL)

M_r1 = molecular weight of hydrocodone bitartrate disesquihydrate, 494.49

M_r2 = molecular weight of anhydrous hydrocodone bitartrate, 449.46

Acceptance criteria: 90.0%–110.0%

4 PERFORMANCE TESTS

Dissolution 〈711〉

Test 1

Medium: Water; 900 mL, deaerated

Apparatus 2: 50 rpm

Time: 30 min

Buffer and Mobile phase: Prepare as directed in the Assay.

Standard solution: 0.0055 mg/mL of USP Hydrocodone Bitartrate RS and 0.00165 mg/mL of USP Homatropine Methylbromide RS in Medium

Sample solution: Pass the solution under test through a suitable filter of 0.45-µm pore size.

Chromatographic system: Proceed as directed in the Assay, with the following exception.

Injection volume: 250 µL

System suitability

Sample: Standard solution

Suitability requirements

Resolution: NLT 13 between homatropine methylbromide and hydrocodone bitartrate

Relative standard deviation: NMT 3.0% for each analyte

Analysis

Samples: Standard solution and Sample solution

Calculate the percentage of the labeled amounts of hydrocodone bitartrate disesquihydrate (C₁₈H₂₁NO₃.C₄H₆O₆. 2½H₂O) and 18  homatropine methylbromide (C₁₇H₂₄BrNO₃) dissolved:

Result = (r_U/r_S ) × C_S × V × (1/L) × (M_r1/M_r2) × 100

r_U = peak area of hydrocodone bitartrate or homatropine methylbromide from the Sample solution

r_S = peak area of hydrocodone bitartrate or homatropine methylbromide from the Standard solution

C_S = concentration of USP Hydrocodone Bitartrate RS or USP Homatropine Methylbromide RS in the Standard solution (mg/mL)

V = volume of Medium, 900 mL

L = label claim for each drug substance (mg/Tablet)

M_r1 = molecular weight of hydrocodone bitartrate disesquihydrate, 494.49

M_r2 = molecular weight of anhydrous hydrocodone bitartrate, 449.46

Tolerances: NLT 80% (Q) of the labeled amounts of hydrocodone bitartrate disesquihydrate (C₁₈H₂₁NO₃.C₄H₆O₆. 2½H₂O) and homatropine 18 methylbromide (C₁₇H₂₄BrNO₃) is dissolved.

Test 2: If the product complies with this test, the labeling indicates that the product meets USP Dissolution Test 2. Medium: Water; 500 mL

Apparatus 2: 50 rpm

Time: 45 min

Mobile phase: 1.4 g/L of octanesulfonic acid sodium salt and 0.1% phosphoric acid in a filtered and degassed mixture of acetonitrile and water (1:3)

Standard solution A: 0.50 mg/mL of USP Hydrocodone Bitartrate RS in Mobile phase

Standard solution B: 0.15 mg/mL of USP Homatropine Methylbromide RS in Mobile phase

System suitability solution: 0.01 mg/mL of USP Hydrocodone Bitartrate RS and 0.003 mg/mL of USP Homatropine Methylbromide RS prepared as follows. Transfer adequate amounts of Standard solution A and Standard solution B to a suitable volumetric flask. Add 21% of the total volume of Mobile phase, and dilute with Medium to volume.

Sample solution: Pass a 20-mL portion of the solution under test through a suitable filter of 0.45-µm pore size, discarding the first 2–3 mL. Mix thoroughly 15.0 mL of the filtrate with 5.0 mL of Mobile phase.

Chromatographic system

(See Chromatography 〈621〉, System Suitability.)

Mode: LC

Detector: UV 212 nm

Column: 3.9-mm × 30-cm; packing L1

Flow rate: 2.0 mL/min

Injection volume: 200 µL System suitability

Sample: System suitability solution

Suitability requirements

Resolution: NLT 2.2 between homatropine methylbromide and hydrocodone bitartrate

Tailing factor: NMT 1.5 for each drug substance

Relative standard deviation: NMT 3.0% for homatropine methylbromide; NMT 2.0% for hydrocodone bitartrate Analysis

Samples: Standard solution A, Standard solution B, and Sample solution

Calculate the percentage of the labeled amounts of hydrocodone bitartrate disesquihydrate (C₁₈H₂₁NO₃.C₄H₆O₆. 2½H₂O) and 18 homatropine methylbromide (C₁₇H₂₄BrNO₃) dissolved:

Result = (r_U/r_S ) × C × D × V × (1/L) × (M_r1/M_r2) × 100

r_U = peak area of hydrocodone bitartrate or homatropine methylbromide from the Sample solution

r_S = peak area of hydrocodone bitartrate or homatropine methylbromide from the Standard solution

C = concentration of USP Hydrocodone Bitartrate RS or USP Homatropine Methylbromide RS in the Standard solution (mg/mL) S

D = dilution factor of the Sample solution

V = volume of Medium, 500 mL

L = label claim for each drug substance (mg/Tablet)

M_r1 = molecular weight of hydrocodone bitartrate disesquihydrate, 494.49

M_r2 = molecular weight of anhydrous hydrocodone bitartrate, 449.46

Tolerances: NLT 75% (Q) of the labeled amounts of hydrocodone bitartrate disesquihydrate (C₁₈H₂₁NO₃.C₄H₆O₆. 2½H₂O) and homatropine 18  methylbromide (C₁₇H₂₄BrNO₃) is dissolved.

Uniformity of Dosage Units 〈905〉: Meets the requirements

5 IMPURITIES

Limit of Dihydrocodeine Bitartrate, Hydrocodone Diol, and Related Substances

Buffer: 0.005 M sodium 1-octanesulfonate. Adjust with glacial acetic acid to a pH of 2.5 ± 0.1.

Mobile phase: Methanol and Buffer (40:60). Add 0.5 mL/L of triethylamine.

System suitability stock solution: 0.02 mg/mL each of hydrocodone diol and USP Dihydrocodeine Bitartrate RS in Mobile phase System suitability solution: 0.1 µg/mL each of hydrocodone diol and USP Dihydrocodeine Bitartrate RS in Mobile phase from the System suitability stock solution

Standard solution and Sample solution: Proceed as directed in the Assay.

Chromatographic system

(See Chromatography 〈621〉, System Suitability.)

Mode: LC

Detector: UV 280 nm

Column: 4.6-mm × 25-cm; 5-µm packing L7

Flow rate: 1.5 mL/min

Injection volume: 200 µL

Run time: NLT 1.7 times the retention time of hydrocodone bitartrate

System suitability

Sample: System suitability solution

Suitability requirements

Resolution: NLT 2.0 between hydrocodone diol and dihydrocodeine bitartrate

Relative standard deviation: NMT 5.0% for both hydrocodone diol and dihydrocodeine bitartrate

Analysis

Sample: Sample solution

Calculate the percentages of hydrocodone diol and dihydrocodeine bitartrate in the portion of Tablets taken:

Result = (r_U/r_T) × 100

r_U = peak response of either hydrocodone diol or dihydrocodeine bitartrate from the Sample solution

r_T = peak response of hydrocodone bitartrate from the Sample solution

Calculate the percentage of each individual related substance in the portion of Tablets taken:

Result = (r_U/r_T) × 100

r_U = peak response of any individual related substance from the Sample solution with a relative retention time of NLT 0.42 in relation to the retention time of hydrocodone bitartrate

r_T = sum of all peak responses from the Sample solution

Acceptance criteria: See Table 1.

Table 1

^a 4,5-Dihydroxy-3-methoxy-17-methylmorphinan-6-one.

Change to read:

Limit of Homatropine Hydrobromide and Related Substances

Buffer: 0.005 M dibasic potassium phosphate. Adjust with phosphoric acid to a pH of 6.4 ± 0.1  . Mobile phase: Acetonitrile and Buffer (30:170). Filter and degas.

Standard solution: 0.6 µg/mL of homatropine hydrobromide in Mobile phase

Sample solution: Proceed as directed in the Assay.

Chromatographic system

(See Chromatography 〈621〉, System Suitability.)

Mode: LC

Detector: UV 210 nm

Column: 4.6-mm × 25-cm; 5-µm packing L7

Flow rate: 1.5 mL/min

Injection volume: 10 µL

Run time: NLT 1.6 times the retention time of hydrocodone bitartrate

System suitability

Sample: Standard solution

Suitability requirements

Relative standard deviation: NMT 5.0%

Analysis

Sample: Sample solution

Calculate the percentage of homatropine hydrobromide in the portion of Tablets taken:

Result = (r_U/r_T) × 100

r_U = peak response of homatropine hydrobromide from the Sample solution

r_T = peak response of homatropine methylbromide from the Sample solution

Calculate the percentage of each individual related substance in the portion of Tablets taken:

Result = (r_U/r_T) × 100

r_U = peak response of any individual related substance from the Sample solution with a relative retention time less than 0.44 in  relation to the retention time of hydrocodone bitartrate

r_T = sum of all peak responses from the Sample solution

Acceptance criteria: See Table 2.

Table 2

^a 4,5-Dihydroxy-3-methoxy-17-methylmorphinan-6-one.

bImpurities are quantified in the test for Limit of Dihydrocodeine Bitartrate, Hydrocodone Diol, and Related Substances are not included in Total impurities.

Limit of Tropine

Standard stock solution: 150 µg/mL of tropine in diethyl ether

Standard solution 1: 75 µg/mL of tropine from the Standard stock solution in diethyl ether

Standard solution 2: 37.5 µg/mL of tropine from the Standard solution 1 in diethyl ether

Standard solution 3: 18.75 µg/mL of tropine from the Standard solution 2 in diethyl ether

Standard solution 4: 9.38 µg/mL of tropine from the Standard solution 3 in diethyl ether

Sample solution: Finely powder 25 Tablets, and add to a centrifuge tube. Pipet 5.0 mL of diethyl ether into the centrifuge tube, mix on a vortex mixer for 5 min, centrifuge, and use the supernatant.

Chromatographic system

(See Chromatography 〈621〉, Thin-Layer Chromatography.)

Application volume: 500 µL

Developing solvent system: Alcohol and ammonium hydroxide (400:100)

Spray reagent: Dissolve 300 mg of platinic acid in 3 mL of diluted hydrochloric acid. Add 97 mL of water and 100 mL of 6% potassium iodide in water, and mix.

Analysis

Samples: Standard stock solution, Standard solution 1, Standard solution 2, Standard solution 3, Standard solution 4, and Sample solution Apply the Standard stock solution, Standard solution 1, Standard solution 2, Standard solution 3, Standard solution 4, and Sample solution to a TLC plate and proceed as directed in the chapter. After the plate has dried, position it in a chamber saturated with iodine vapor for about 30 min, then place it in a hood to allow the iodine to sublime from the plate, and spray the plate with Spray reagent until spots appear.

Acceptance criteria: Any spot from the Sample solution occurring at an R value corresponding to tropine is not greater in size or intensity F than the corresponding spot from Standard solution 2 (0.5%); NMT 0.5% of tropine.

6 ADDITIONAL REQUIREMENTS

Packaging and Storage: Preserve in tight, light-resistant containers.

Labeling: When more than one Dissolution test is given, the labeling states the Dissolution test used only if Test 1 is not used. USP Reference Standards 〈11〉

USP Dihydrocodeine Bitartrate RS

USP Homatropine Methylbromide RS

USP Hydrocodone Bitartrate RS

₁ A suitable grade is available from Analytical Research and Testing, Somerville, NJ; Fax: 908-725-8848.
