Heparin Sodium

This article is compiled based on the United States Pharmacopeia (USP) – 2025 Edition

Issued and maintained by the United States Pharmacopeial Convention (USP)

DOWNLOAD PDF HERE

1 DEFINITION

Heparin Sodium is the sodium salt of sulfated glycosaminoglycans present as a mixture of heterogeneous molecules varying in molecular weights that retains a combination of activities against different factors of the blood clotting cascade. It is present in mammalian tissues and is usually obtained from the intestinal mucosa or other suitable tissues of domestic mammals used for food by humans. The sourcing of heparin material must be specified in compliance with applicable regulatory requirements. The manufacturing process should be validated to demonstrate clearance and inactivation of relevant infectious and adventitious agents (e.g., viruses, TSE agents). See Viral Safety Evaluation of Biotechnology Products Derived from Cell Lines of Human or Animal Origin (1050) for general guidance on viral safety evaluation. The heparin manufacturing process should also be validated to demonstrate clearance of lipids. It is composed of polymers of alternating derivatives of α-D-glucosamido (N-sulfated, O-sulfated, or N-acetylated) and O-sulfated uronic acid (α-L-iduronic acid or β-D-glucuronic acid). The component activities of the mixture are in ratios corresponding to those shown by USP Heparin Sodium for Assays RS. Some of these components have the property of prolonging the clotting time of blood. This occurs mainly through the formation of a complex of each component with the plasma proteins antithrombin and heparin cofactor II to potentiate the inactivation of thrombin (factor Ila). Other coagulation proteases in the clotting sequence, such as activated factor X (factor Xa), are also inhibited. The ratio of anti-factor Xa activity to anti-factor Ila potency is between 0.9 and 1.1. The potency of Heparin Sodium, calculated on the dried basis, is NLT 180 USP Heparin Units in each mg.

2 IDENTIFICATION

2.1 A. 1H NMR SPECTRUM

(See Nuclear Magnetic Resonance Spectroscopy (761).)

Standard solution: NLT 20 mg/mL of USP Heparin Sodium Identification RS in deuterium oxide with 0.002% (w/v) deuterated trimethylsilylpropionic (TSP) acid sodium salt

System suitability solution: Prepare 0.3% (w/w) USP Oversulfated Chondroitin Sulfate RS in the Standard solution.

Sample solution: NLT 20 mg/mL of Heparin Sodium in deuterium oxide with 0.002% (w/v) deuterated TSP. [NOTE-EDTA may be added to the Sample solution to NMT 12 µg/mL. In the event that EDTA is added to the Sample solution, spectra should be recorded and compared both with and without addition of EDTA.]

Instrumental conditions

(See Nuclear Magnetic Resonance Spectroscopy (761).)

Mode: NMR, pulsed (Fourier transform)

Frequency: NLT 500 MHz (for ¹H)

Temperature: 20°-30°

System suitability

Samples: Standard solution and System suitability solution

Using a pulsed (Fourier transform) NMR spectrometer operating at NLT 500 MHz for ¹H, acquire a free induction decay (FID) using NLT 16 scans using a 90° pulse, an acquisition time of NLT 2 s, and at least a 10-s delay. Record the ¹H NMR spectra of the Standard solution and the System suitability solution at a stable temperature between 20°-30°. Collect the ¹H NMR spectrum with a spectral window of at least 10 to -2 ppm and without spinning. The number of transients should be adjusted until the signal-to-noise ratio of the N-acetyl heparin signal in the Standard solution is at least 1000/1 in the region near 2 ppm. The Standard solution shall be run at least daily when Sample solutions are being run. For all samples, the TSP methyl signal should be set to 0.00 ppm. The chemical shift for the N-acetyl resonance of heparin and oversulfated chondroitin sulfate in the System suitability solution should be observed at 2.05 ± 0.02 and 2.16 ± 0.03 ppm, respectively. Record the ¹H NMR spectrum of the Sample solution at a stable temperature between 20°-30°. Draw a baseline from 8.00 ppm to 0.10 ppm. The ppm values for H1 of GlcNAc/GIcNS, 6S (signal 1), H1 of IdoA2S (signal 2), the H2 of GIcNS (signal 3), and the methyl of GlcNAc (signal 4) of heparin are present at 5.42, 5.21, 3.28 (doublet centered at 3.28 ppm), and 2.05 ppm, respectively.¹ The chemical shifts of these signals do not differ by more than ±0.03 ppm. Measure the signal heights above the baseline of signal 1 and signal 2, and calculate the mean of these signal heights. Other signals of variable heights and ppm values, attributable to heparin and HOD, may be seen between signal 2 and 4.55 ppm. Residual solvent signals may be observed in the 0.10-3.75 range. Heparin Sodium must meet the requirements stated in Residual Solvents (467).

Suitability requirements

Number of transients: Adjust until the signal-to-noise ratio of the N-acetyl heparin signal in the Standard solution is at least 1000/1 in the region near 2 ppm.

Chemical shift: The TSP methyl signal should be set to 0.00 ppm for all samples.

Chemical shifts (for the N-acetyl resonance of heparin and oversulfated chondroitin sulfate in the System suitability

solution): Should be observed at 2.05 ± 0.02 and 2.16 ± 0.03 ppm, respectively

Analysis

Sample: Sample solution

Acceptance criteria: No unidentified signals greater than 4% of the mean of the height of signals 1 and 2 are present in the following ranges: 0.10-2.00, 2.10-3.20, and 5.70-8.00 ppm. No signals greater than 200% of the mean of the height of signals 1 and 2 are present in the 3.75-4.55 ppm for porcine heparin.

2.2 B. CHROMATOGRAPHIC IDENTITY

Solution A: Dissolve 0.8 g of monobasic sodium phosphate dihydrate in 2 L of water, and adjust with phosphoric acid to a pH of 3.0. Pass the solution through a membrane filter with a 0.45-µm pore size, and degas before use.

Solution B: Dissolve 0.8 g of monobasic sodium phosphate dihydrate and 280 g of sodium perchlorate monohydrate in 2 L of water, and adjust with phosphoric acid to a pH of 3.0. Pass the solution through a membrane filter with a 0.45-µm pore size, and degas before use.

Mobile phase: See Table 1.

Table 1

Standard solution: NLT 20 mg/mL of USP Heparin Sodium Identification RS in water

System suitability solution: Prepare 0.1% (w/w) USP Oversulfated Chondroitin Sulfate RS and 0.5% (w/w) USP Dermatan Sulfate RS in the Standard solution.

Sample solution: NLT 20 mg/mL of Heparin Sodium in water

Chromatographic system

(See Chromatography (621), System Suitability.)

Mode: LC

Detector: UV 202 nm

Column: 2-mm x 25-cm; packing L81²

Guard column: 2-mm x 5-cm; packing L61

Column temperature: Maintain columns at 40°

Flow rate: 0.22 mL/min

Injection volume: 20 µL

System suitability

Sample: System suitability solution

[NOTE-The retention times for dermatan sulfate, heparin, and oversulfated chondroitin sulfate are about 17, 22, and 30 min, respectively.]

Suitability requirements

Resolution: NLT 1.0 between the dermatan sulfate and heparin peaks, and NLT 1.5 between the heparin and oversulfated chondroitin sulfate peaks

Relative standard deviation: NMT 2% for the heparin peak area determined from three replicate injections

Analysis

Samples: Standard solution and Sample solution

Record the chromatograms, and measure the retention times for the major peaks.

Acceptance criteria: The retention time of the major peak of the Sample solution corresponds to that of the Standard solution.

2.3 C. ANTI-FACTOR FAR TO ANTI-FACTOR IIa RATIO

ANTI-FACTOR XA AND ANTI-FACTOR IIA ASSAYS FOR UNFRACTIONATED AND LOW MOLECULAR WEIGHT HEPARINS (208), Anti-Factor Xa and Anti-Factor Ila Assays for Unfractionated Heparin

Acceptance criteria: 0.9-1.1

2.4 D. MOLECULAR WEIGHT DETERMINATIONS

1 M ammonium acetate solution: Accurately weigh 77.1 g of ammonium acetate, and dissolve in 1 L of water.

1% sodium azide solution: Dissolve 1 g of sodium azide in 100 mL of water.

Mobile phase: Transfer 100 mL of 1 M ammonium acetate solution to a 1-L volumetric flask, add 20 mL of 1% sodium azide solution, and dilute with water to volume. Filter using a nylon membrane with a 0.2-µm pore size prior to use.

Calibration solution: Prepare by dissolving 10 mg of the USP Heparin Sodium Molecular Weight Calibrant RS in 2 mL of Mobile phase, and filter using a nylon membrane with a 0.2-µm pore size.

System suitability solution: 5 mg/mL of USP Heparin Sodium Identification RS in Mobile phase. Filter using a nylon membrane with a 0.2-µm pore size.

Sample solution: Dissolve about 10 mg of Heparin Sodium sample in 2 mL of Mobile phase, and filter using a nylon membrane with a 0.2-µm pore size.

Chromatographic system

(See Chromatography (621), System Suitability..)

[NOTE-The temperature of the refractive index detector must be set at the same temperature as the Column temperature.]

Mode: LC

Detector: Refractive index

Columns: One 7.8-mm × 30-cm, 8-µm packing L59 in series with a 7.8-mm x 30-cm, 5-µm packing L59³

Guard column: 6-mm x 4-cm; 7-µm packing L59

Column temperature: 30°

Flow rate: 0.6 mL/min ± 0.1%

Column equilibration: 0.6 mL/min for 2 h

Injection volume: 20 µL

System suitability

Samples: Calibration solution and System suitability solution (duplicate injections)

Suitability requirements

Weight-average molecular weight (M_W): Take the mean of the calculated M_W from the duplicate injections of the System suitability solution, and round to the nearest 100 Da. The chromatographic system is suitable if the M_W of the System suitability sample is within 500 Da of the labeled value as stated in the USP Certificate for USP Heparin Sodium Identification RS.

Peak molecular weights (M_P): The peak molecular weights (M_P) of the duplicate injections of the System suitability solution do not differ by more than 5% of the upper value.

Resolution: There is baseline resolution between the heparin and salt peaks.

Calibration curve: The linear regression coefficient of the calibration curve fitted to the Broad Standard Table values must be NLT 0.990, using a third-order polynomial equation.

Analysis

Samples: Inject 20 µL of the System suitability solution (duplicate injections), Sample solution (duplicate injection), and Calibration solution (single injection), and record the chromatograms for a length of time to ensure complete elution, including salt and solvent peaks (about 50 min). [NOTE-The calibrant, standard, or sample of heparin will give a broad heparin peak between about 20 and 40 min, followed by a later eluting narrow salt peak, as illustrated in the USP Certificate for USP Heparin Sodium Molecular Weight Calibrant RS.]

Calculations: Calculate the total area under the heparin peak in the Calibration solution chromatogram, and the cumulative area at each point under the peak as a percent of the total. Do not include the salt peak. Using the Broad Standard Table provided in the USP Certificate for USP Heparin Sodium Molecular Weight Calibrant RS, identify those points in the chromatogram for which the percent cumulative area is closest to the percent fractions listed in the Table, and assign the molecular weight (MW) in the Table to the corresponding retention time (RT) in the chromatogram. For the set of retention times and molecular weights identified, fit log(MW) vs. RT to a third-order polynomial function using suitable gel permeation chromatography (GPC) software [or: find values of a, b, c, and d such that log(MW) = a + b(RT) + c(RT)² + d(RT)³].

Using the same GPC software, for each of the duplicate chromatograms of the System suitability solution and the Sample solution, with the calibration function derived as described above, calculate M_W according to the following formula:

M_W = Σ(RI_iM_i)/ΣRI_i

where the detector response at each point is defined as RI_i and the MW at each point as M_i. Round the mean value of M_W to the nearest 100 Da.

Using the same GPC software, determine for each of the duplicate Sample solution chromatograms: the percentage of heparin with molecular weight in the range 8,000-16,000, M_8000-16000 the percentage of heparin with molecular weight in the range 16,000-24,000, M_16000-24000 and the percentage of heparin with molecular weight greater than 24,000, M₂₄₀₀₀ Round the mean percentage values to the nearest 1%.

Acceptance criteria: M24000 is NMT 20%, M_W is between 15,000 Da and 19,000 Da, and the ratio of M_8000-16000 to M_16000-24000 is NLT 1.0.

E. A solution of Heparin Sodium imparts an intense yellow color to a nonluminous flame.

3 ASSAY

ANTI-FACTOR IIA POTENCY

ANTI-FACTOR XA AND ANTI-FACTOR IIA ASSAYS FOR UNFRACTIONATED AND LOW MOLECULAR WEIGHT HEPARINS (208), Anti-Factor Ila Activity for Unfractionated Heparin

Acceptance criteria: The potency of Heparin Sodium, calculated on the dried basis, is NLT 180 USP Heparin Units in each mg.

4 OTHER COMPONENTS

NITROGEN DETERMINATION (461), Method I: 1.3%-2.5%, calculated on the dried basis, using the procedure for Nitrates and Nitrites Absent

5 IMPURITIES

5.1 RESIDUE ON IGNITION (281)

28.0%-41.0%

5.2 LIMIT OF GALACTOSAMINE IN TOTAL HEXOSAMINE (a measure of dermatan sulfate and other galactosamine containing impurities)

Mobile phase: 14 mM potassium hydroxide

Glucosamine standard solution: 1.6 mg/mL of USP Glucosamine Hydrochloride RS in 5 N hydrochloric acid

Galactosamine standard solution: 16 µg/mL of USP Galactosamine Hydrochloride RS in 5 N hydrochloric acid

Standard solution: Mix equal volumes of the Glucosamine standard solution and the Galactosamine standard solution.

Hydrolyzed standard solution: Transfer 5 mL of the Standard solution to a 7-mL screw-cap test tube, cap, and heat for 6 h at 100°. Cool to room temperature, and dilute with water (1 in 100).

Sample solution: Transfer 12 mg of Heparin Sodium to a 7-mL screw-cap test tube, dissolve in 5 mL of 5 N hydrochloric acid, and cap.

Hydrolyzed sample solution: Heat the Sample solution for 6 h at 100°. Cool to room temperature, and dilute with water (1 in 100).

Chromatographic system

(See Chromatography (621), System Suitability.)

Mode: HPlC

Detector: Pulsed amperometric detector, set to the following waveform. See Table 2.

Table 2

Column: 3-mm x 3-cm Amino acid trap column in series with a 3-mm x 3-cm guard column and a 3-mm x 15-cm column that contains packing L69

Column temperature: 30°

Flow rate: 0.5 mL/min

Pre-equilibration: At least 60 min with Mobile phase

Injection volume: 10 µL

Elution: 10 min with Mobile phase

Column cleaning: At least 10 min with 100 mM potassium hydroxide

Equilibration: At least 10 min with Mobile phase before each injection

System suitability

Sample: Hydrolyzed standard solution

Suitability requirements

Resolution: NLT 2 between the galactosamine and glucosamine peaks

Column efficiency: NLT 2000 theoretical plates for glucosamine

Tailing factor: Between 0.8 and 2.0 for the galactosamine and glucosamine peaks

Analysis

Samples: Hydrolyzed standard solution and Hydrolyzed sample solution

Record the chromatograms, and measure the responses for the peaks at the retention time of galactosamine and glucosamine.

Calculate the response ratio of galactosamine to glucosamine (GalN_R) in the Hydrolyzed standard solution:

Result = (GalN_B/GaIN_W) x (GIcN_W/GIcN_B)

GalN_B = peak area of galactosamine from the Hydrolyzed standard solution

GaIN_W = weight of galactosamine for the Standard solution

GIcN_W = weight of glucosamine for the Standard solution

GIcN_B = peak area of glucosamine from the Hydrolyzed standard solution

Calculate the percentage of galactosamine in the portion of total hexosamine taken:

Result = {[(GalN_U/GalN_R)]/[(GalN_U/GalN_R) + GIcN_U]} x 100

GalN_U = peak area of galactosamine from the Hydrolyzed sample solution

GalN_R = response ratio of galactosamine

GIcN_U = peak area of glucosamine from the Hydrolyzed sample solution

Acceptance criteria: The percent galactosamine peak area of the total hexosamine of the Hydrolyzed sample solution must be NMT 1%.

5.3 NUCLEOTIDIC IMPURITIES

Solution A: Dissolve 3.08 g of ammonium acetate in 2 L of water, and adjust with glacial acetic acid to a pH of 4.4 ± 0.2. Degas for 2 min under vacuum with sonication before use.

Solution B: 100% acetonitrile. Degas for 1 min under vacuum with sonication before use.

Mobile phase: See Table 3.

Table 3

Nucleoside identification solution: Accurately weigh and transfer about 25 mg each of uridine, guanosine, cytidine, thymidine, 2'-deoxyadenosine, 2'-deoxyguanosine, 2'-deoxycytidine, and 5-methyl-2'-deoxycytidine into a 200-mL volumetric flask, add approximately 185 mL of water, and dissolve with sonication and vortexing, if necessary. Dilute with water to volume, and mix. Transfer 2.0 mL of this solution into a 100-mL volumetric flask, dilute with water to volume, and mix.

Adenosine stock solution: Accurately weigh and transfer 25 mg of USP Adenosine RS into a 100-mL volumetric flask, add approximately 85 mL of water, and dissolve with sonication and vortexing, if necessary. Dilute with water to volume, and mix.

Standard solution: Transfer 2.0 mL of the Adenosine stock solution into a 200-mL volumetric flask, dilute with water, and mix.

System suitability solution: Transfer 2.0 mL of the Standard solution into a 100-mL volumetric flask, dilute with water to volume, and mix.

Reaction buffer: Accurately weigh and transfer 0.41 g of magnesium chloride hexahydrate, 0.24 g of tris (hydroxymethyl)amino methane, and 0.58 g of sodium chloride into a 100-mL volumetric flask, dissolve in 75 mL of water, and mix. Adjust with 1 N hydrochloric acid to a pH of 7.9 ± 0.1. Dilute with water to volume, and mix.

PDE I diluent: Transfer 5.0 mL of Glycerol and 5.0 mL of the Reaction buffer into a 20-mL flask, and vortex to mix.

PDE I solution: 0.1 unit/µL of phosphodiesterase I (PDE I) in PDE I diluent. Store at -20°.

Enzyme digest solution: Add 10 µL of Benzonase,⁴ 222 Units of alkaline phosphase (AP), and 125 µL of PDE I solution to 5.0 mL of Reaction buffer. Store at -20°.

Blank: Transfer 100 µL of water and 100 µL of Enzyme digest solution into a 250-µL HPLC vial, and mix with a micropipette. Incubate NLT 60 min in the autosampler at 37° before injection.

Sample solution: Accurately weigh and transfer 400 mg of Heparin Sodium into a 20-mL volumetric flask, dilute with water to volume, and mix. Transfer 100 µL of this solution and 100 µL of Enzyme digest solution into a 250-µL HPLC vial, and mix. Incubate NLT 60 min in the autosampler at 37° before injection.

Chromatographic system

(See Chromatography (621), System Suitability.)

Mode: LC

Column: 4.6-mm x 15-cm; 4-µm packing L1

Detector: UV 260 nm

Autosampler temperature: 37 ± 1°

Column temperature: 20 ± 3°

Flow rate: 1 mL/min

Injection volume: 10 µL

Run time: 25 min

System suitability

Samples: Nucleoside identification solution, Standard solution, and System suitability solution

Suitability requirements

Resolution: The resolution between the 2'-deoxycytidine peak and the uridine peak is NLT 1.3 for the injection of the Nucleoside identification solution.

Relative standard deviation: Inject six replicates of the Standard solution, and record the chromatograms. The percent relative standard deviation (%RSD) of the areas of the adenosine peak is NMT 10%.

Signal-to-noise ratio: The S/N of the adenosine peak in the System suitability solution is NLT 10.

Analysis

Samples: Water, Blank, Nucleoside identification solution, Standard solution, System suitability solution, and Sample solution Record the chromatograms.

Calculate the area reject value, Q:

Q = (10 x A_SSS)/(S/N)

A_SSS = peak area of adenosine in the System suitability solution

S/N = signal-to-noise ratio of the adenosine peak in the System suitability solution

For the Standard solution, calculate the concentration of adenosine, in mg/mL:

C_S = W_S/DF

C_S = concentration of adenosine in the Standard solution (mg/mL)

W_S = weight of USP Adenosine RS (mg)

DF = 10,000 (dilution factor)

Calculate the percentage of nucleotidic impurities:

Result = Σ[(C_S/A_S) x A_l x (MW_ratio/RRF_i)] x (DF/W_sample) x 100

C_S = concentration of adenosine in the Standard solution (mg/mL)

A_S = average peak area (n = 6) of adenosine in the Standard solution

A_l = peak area of each impurity above Q in the Sample solution

MW_ratio = see Table 4

RRF_i = relative response factor for the corresponding peak (see Table 4)

DF = dilution factor, 40

W_sample = sample weight of Heparin Sodium (mg)

Table 4

Acceptance criteria: NMT 0.1% (w/w) is found.

5.4 ABSENCE OF OVERSULFATED CHONDROITIN SULFATE

A. Proceed as directed in IdentificationA. No features associated with oversulfated chondroitin sulfate are found between 2.12 and 3.00 ppm.

B. Proceed as directed in IdentificationB. No peaks corresponding to oversulfated chondroitin sulfate should be detected eluting after the heparin peak.

5.5 PROTEIN IMPURITIES

[NOTE-Treatment for interfering substances is only required for samples previously tested with a protein content greater than 0.1%. Spiked sample should be prepared and assayed only if the treatment for interfering substances is performed.]

Standard stock solution: 2.0 mg/mL of bovine serum Albumin in water

Standard solutions: Dilute portions of the Standard stock solution with water to obtain NLT 5 standard solutions having concentrations between 0.010 and 0.050 mg/mL of bovine serum albumin, the concentrations being evenly spaced.

System suitability standard: Dilute a portion of the Standard stock solution with water to obtain a solution containing 0.030 mg/mL of bovine serum albumin.

Sample solution: 30 mg/mL of Heparin Sodium in water. Prepare in triplicate.

Spiked sample: Using an appropriate dilution scheme and the Standard stock solution, prepare a Spiked sample containing 30 mg/mL Heparin Sodium and 0.030 mg/mL bovine serum albumin in water.

Blank: Water

Lowry reagent A: Prepare a solution of 10 g/L of sodium hydroxide in water and a solution of 50 g/L of sodium carbonate in water. Mix equal volumes (2V:2V) of each solution, and dilute with water to 5V.

Lowry reagent B: Prepare a solution of 29.8 g/L of disodium tartrate dihydrate in water. Prepare a solution of 12.5 g/L of cupric sulfate in water. Mix equal volumes of both solutions (2V:2V), and dilute with water to 5V.

Lowry reagent C: Mix 50 volumes of Lowry reagent A with 1 volume of Lowry reagent B. Prepare fresh daily.

Diluted Folin-Ciocalteu's phenol reagent: Dilute Folin-Ciocalteu's phenol reagent 1-2 times with water. The dilution should be chosen such that the pH of the samples (i.e., Standard solution and Sample solution after addition of Lowry reagent C and the Diluted Folin-Ciocalteu's phenol reagent) is 10.3 ± 0.3.

Sodium deoxycholate reagent: Prepare a solution of sodium deoxycholate in water having a concentration of 150 mg in 100 mL.

Trichloroacetic acid reagent: Prepare a solution of trichloroacetic acid in water having a concentration of 72 g in 100 mL.

Analysis

Samples: Standard solutions, Sample solution, and Blank

To 1 mL each of Standard solution, Sample solution, and Blank, add 5 mL of Lowry reagent C. Mix. Allow to stand at room temperature for 10 min. Add 0.5 mL of Diluted Folin-Ciocalteu's phenol reagent to each solution, mix immediately, and allow to stand at room temperature for NLT 30 min. Determine the absorbance at the wavelength of maximum absorbance at 750 nm with a suitable spectrophotometer, using the solution from the Blank to set the instrument to zero and ensuring that all samples and standards absorbances are measured after the same final incubation time. To remove interfering substances, add 0.1 mL of Sodium deoxycholate reagent to 1 mL of a solution of the protein under test. Mix on a vortex mixer, and allow to stand at room temperature for 10 min. Add 0.1 mL of Trichloroacetic acid reagent, and mix on a vortex mixer. Centrifuge at a speed that ensures removal of visible particulate matter. [NOTE-NLT 14,100 RCF should be used. Appropriate centrifuge speed should be determined by each laboratory.] The supernatant should be essentially free of visible particulates. A pellet may not be visible. If the interfering substances method is used, dissolve the protein residue in 1 mL of Lowry reagent C.

Calculations: Using the linear regression method, plot the absorbances of the solutions from the Standard solutions versus the protein concentrations, and determine the standard curve best fitting the plotted points. From the standard curve so obtained and the absorbance of the Sample solution, determine the concentration of protein in the Sample solution.

System suitability: The correlation coefficient (r) for a linear fit of all standards is NLT 0.99. The percent RSD between triplicate sample results is NMT 10%. If the sample absorbances are lower than the standard curve, the percent RSD specification is not required. The percent recovery of the System suitability standard is 90%-110%. If the interfering substances treatment is performed, the percent recovery of the Spiked sample is 85%-115%.

Acceptance criteria: NMT 0.1% (w/w) is found.

6 SPECIFIC TESTS

6.1 BACTERIAL ENDOTOXINS TEST (85)

It contains NMT 0.03 USP Endotoxin Units/USP Heparin Unit.

6.2 LOSS ON DRYING (731)

Analysis: Dry a sample in a vacuum at 60° for 3 h.

Acceptance criteria: It loses NMT 5.0% of its weight.

6.3 PH(791)

5.0-7.5 in a solution (1 in 100)

6.4 STERILITY TESTS (71)

Where it is labeled as sterile, it meets the requirements.

7 ADDITIONAL REQUIREMENTS

7.1 PACKAGING AND STORAGE

Preserve in tight containers, and store below 40°, preferably at room temperature.

7.2 LABELING

Label it to indicate the tissue and the animal species from which it is derived.

USP REFERENCE STANDARDS (11)

USP Adenosine RS

USP Oversulfated Chondroitin Sulfate RS

USP Dermatan Sulfate RS

USP Galactosamine Hydrochloride RS

USP Glucosamine Hydrochloride RS

USP Heparin Sodium Identification RS

USP Heparin Sodium Molecular Weight Calibrant RS

¹ GlcNAc, N-acetylated glucosamine; GIcNS, N-sulfated glucosamine; S, sulfate; IdoA, iduronic acid; GIcN, glucosamine; GalN, galactosamine.

² L81-A hydroxide-selective, strong anion-exchange resin consisting of a highly cross-linked core of 9 µm porous particles having a pore size of 2000 Å units and consisting of ethylvinylbenzene cross-linked with 55% divinylbenzene with a latex coating composed of 70 nm diameter microbeads (6% crosslinked) bonded with alkanol quaternary ammonium ions (A suitable column is Dionex lonPac AS11-HC available from www.thermofisher.com).

³ The method was validated using a guard column TSK SWXL 6-mm x 4-cm, 7-µm in series with two analytical columns: TSK G4000 SWXL 7.8-x 30-cm, 8-µm in series with a TSK G3000 SWXL 7.8- x 30-cm, 5-µm diameter.

⁴ A suitable ultrapure Serratia marcescens nuclease (EC 3.1.30.2) must be ≥99% containing ≥25 units/µL.
