Corn Syrup

This article is compiled based on the United States Pharmacopeia (USP) – 2025 Edition

Issued and maintained by the United States Pharmacopeial Convention (USP)

DOWNLOAD PDF HERE

CAS RN: 8029-43-4.

1 DEFINITION

Corn Syrup is an aqueous solution of saccharides obtained by partial hydrolysis of edible corn starch by food grade acids and/or enzymes. It contains NLT 20.0% reducing sugar content (dextrose equivalent) expressed as D-glucose, calculated on the dried basis.

2 IDENTIFICATION

A.

Analysis: Add a few drops of a solution of Syrup (1 in 20) to 5 mL of hot, alkaline cupric tartrate TS.

Acceptance criteria: A copious, red precipitate of cuprous oxide is formed.

3 ASSAY

REDUCING SUGARS (DEXTROSE EQUIVALENT)

Apparatus: Mount a ring support on a ring stand 1-2 in above a gas burner, and mount a second ring 6-7 in above the first. Place 6-in open-wire gauze on the lower ring to support a 250-mL conical flask, and place a 4-in watch glass with a center hole on the upper ring to deflect heat. Attach a 25-mL buret to the ring stand so that the tip just passes through the watch glass centered above the flask. Place an indirectly lighted white surface behind the assembly for observing the endpoint.

Standard solution: 6 mg/mL of USP Dextrose RS

Sample solution: 10 mg/mL of Corn Syrup

Analysis: Transfer 25.0-mL portions of alkaline cupric tartrate TS to each of two flasks, and boil. Immediately place one flask on the wire gauze of the Apparatus, and adjust the burner so that the boiling point is reached in about 2 min. Titrate with the Standard solution to within 0.5 mL of the anticipated endpoint. Heat the flask, with swirling, boil moderately for 2 min, and add 2 drops of methylene blue solution (1 in 100). Immediately add 2 drops of the Standard solution from the buret, and bring to a boil. Allow the cuprous oxide to settle slightly, and observe the color of the supernatant. Complete the titration within 1 min by adding the Standard solution dropwise, and boil after each addition to the disappearance of the blue color, as determined by viewing against a white background in daylight or under equivalent illumination. If more than 0.5 mL of the titrant is required after the addition of the indicator, repeat the titration, adding the necessary volume of titrant before adding the indicator. Bring the contents of the second flask to a boil, and similarly titrate with the Sample solution. Calculate the percentage of reducing sugars as D-glucose, calculated on the dried basis, in the portion of Corn Syrup taken:

Result = (C_s /C_u ) × (V_s /V_u ) × [1/(0.01 × A)] × 100

C_s = concentration of USP Dextrose RS in the Standard solution (mg/mL)

C_u = concentration of Corn Syrup in the Sample solution (mg/mL)

V_s = titrated volume of the Standard solution (mL)

V_u = titrated volume of the Sample solution (mL)

A = percentage of dry solids in Corn Syrup measured by the refractive index

Acceptance criteria: NLT 20.0% reducing sugar content on the dried basis

4 IMPURITIES

RESIDUE ON IGNITION (281)

Sample: 20 g

Acceptance criteria: NMT 0.5%

4.1 LIMIT OF LEAD

[NOTE-For the preparation of all aqueous solutions and for the rinsing of glassware before use, use water that has been passed through a strong-acid, strong-base, mixed-bed ion-exchange resin. For digestion, use acid-cleaned, high-density polyethylene, polypropylene, polytef, or quartz tubes. Select all reagents to have as low a content of lead as practicable, and store all reagent solutions in borosilicate glass containers. Cleanse glassware before use by soaking in warm 8 N nitric acid for 30 min and rinsing with deionized water. Store final diluted solutions in acid-cleaned plastic or polytef tubes or bottles.]

Modifier solution: 200 mg/mL of magnesium nitrate. Just before use, transfer 1.0 mL of this solution to a 10-mL volumetric flask, and dilute with 5% nitric acid to volume.

Standard stock solution: Transfer 10.0 mL of lead nitrate stock solution TS to a 100-mL volumetric flask, add 40 mL of water and 5 mL of nitric acid, and dilute with water to volume. Transfer 1.0 mL of this solution to a second 100-mL volumetric flask, dilute with 5% nitric acid to volume, and mix. This solution contains 0.1 µg/mL of lead.

Standard solutions: Transfer portions of Standard stock solution to four suitable containers, and dilute with 5% nitric acid to obtain Standard solutions having lead concentrations of 100, 50, 25, and 10 ng/mL, respectively.

Sample solution: [NOTE-Perform this procedure in a fume hood.] Transfer 1.5 g of Corn Syrup to a digestion tube, and add 0.75 mL of nitric acid to the tube. Warm the solution slowly (to avoid spattering) to 90°-95°. Heat until all brown vapors have dissipated and any rust-colored tint has disappeared from the tube (20-30 min). Cool, add 0.5 mL of 50% hydrogen peroxide, dropwise, to the solution, heat to 90°-95° for 5 min, and cool. Add a second 0.5-mL portion of 50% Hydrogen peroxide dropwise to the solution, and heat to 90"-100" until clear (5-10 min). Cool, and transfer the solution to a 10-mL volumetric flask. Rinse the digestion tube with 5% nitric acid, add the rinse to the volumetric flask, dilute with 5% nitric acid to volume, and mix.

Standard blank: 5% Nitric acid

Sample blank: Transfer 1.5 g of water to a digestion tube, and proceed as directed for the Sample solution, beginning with "add 0.75 mL of nitric acid".

Instrumental conditions

Mode: Graphite furnace atomic absorption with pyrolytically coated graphite tubes and adequate means of background correction

Lamp: Lead hollow-cathode

Analytical wavelength: Lead emission line of 283.3 nm

Furnace program: See Table 1. (NOTE-The temperature program may be modified to obtain optimum furnace temperatures.]

Table 1

Injection volume: 20 µL

Analysis

[NOTE-Use peak area measurements for all quantitations.]

Samples: Add 5 µL of the Modifier solution to 20 µL each of the Standard solutions, the Sample solution, the Standard blank, and the Sample blank, and mix.

Separately inject equal volumes (about 20 µL) of the Samples into the instrument for analysis. Using the Standard blank to set the instrument to zero, determine the integrated absorbances of the Standard solutions. Plot the integrated absorbances of the Standard solutions versus their contents of lead, in ng/mL, and draw the line best fitting the four points to determine the calibration curve. Similarly determine the integrated absorbances of the Sample solution and the Sample blank. Correct the absorbance value of the Sample solution by subtracting from it the absorbance value obtained from the Sample blank.

Calculate the concentration of lead in the portion of Corn Syrup taken:

Result = (C_L × V/W) × F

C_L = concentration of lead in the Sample solution, as determined from the calibration curve (ng/mL)

V = volume of the Sample solution, 10 mL

W = weight of Corn Syrup taken to prepare the Sample solution (g)

F = conversion factor, 10⁻³ µg/ng

Acceptance criteria: NMT 0.5 µg/g

4.2 LIMIT OF SULFUR DIOXIDE

Starch indicator solution: Mix 10 g of soluble starch with 50 mL of cold water, transfer to 1000 mL of boiling water, stir until completely dissolved, cool, and add 1 g of salicylic acid preservative. [NOTE-Discard this solution after 1 month.]

Sample: 100 g

Blank: 200 mL of water

Titrimetric system

(See Titrimetry (541).)

Mode: Direct titration

Titrant: 0.005 N iodine VS

Endpoint detection: Visual

Analysis: Transfer the Sample to a 250-mL conical flask, add 100 mL of water, and mix. Cool to 5^o-10^o. While stirring with a magnetic stirrer, add 10 mL of cold (5°-10°) 1.5 N sodium hydroxide. Stir for an additional 20 s, and add 10 mL of Starch indicator solution. Add 10 ml. of cold (5-10°) 2.0 N sulfuric acid, and titrate immediately with Titrant until a light blue color persists for 1 min. Perform a blank determination, and make any necessary correction.

Calculate the concentration, in ppm (µg/g), of sulfur dioxide (SO₂) in the Sample taken:

Result = [(V_S − V_B ) × N × F₁ /W] × F₂

V_S = Titrant volume consumed by the Sample (mL)

V_B = Titrant volume consumed by the Blank (mL)

N = actual normality of the Titrant (mEq/mL)

F₁ = equivalency factor, 32.0 mg/mEq

W = Sample weight (g)

F₂ = conversion factor, 10³ µg/mg

Acceptance criteria: NMT 40 µg/g

4.3 ABSENCE OF SOLUBLE STARCH

Analysis: Dissolve 1 g in 10 mL of water, and add 1 drop of iodine TS.

Acceptance criteria: A yellow color indicates the absence of soluble starch.

5 SPECIFIC TESTS

MICROBIAL ENUMERATION TESTS (61) and TESTS FOR SPECIFIED MICROORGANISMS (62): The total aerobic microbial count does not exceed 10^-3 cfu/g, and the total combined molds and yeasts count does not exceed 102 cfu/g.

TOTAL SOLIDS

Instrumental conditions

(See Refractive Index (831).)

Mode: Refractometer equipped with a jacket for water circulation or some other mechanism for maintaining the sample at 20 ± 0.1° or 45 ± 0.1° Before proceeding with measurements, ensure that the sample and the prism have reached the equilibrium temperature and that the instrument has been properly checked and calibrated against a standard provided by the manufacturer.

Analysis: Measure the refractive index of Corn Syrup, and convert the value to approximate percent solids value using Table 2 and Table 3.

[NOTE-Table 2 covers the approximate total solids levels of these products in commerce. If the ash or dextrose equivalent of the sample differs from that of the product in Table 2, use Table 3 for the ash and dextrose equivalent correction.]

Table 2. Reference for Converting the Refractive Index to Approximate Percent Solids

Table 3. Ash and Dextrose Equivalent (DE) Corrections for Corn Syrup: Changes in Refractive Index for an Increase in Dry Substance (DS)

Acceptance criteria: The total solids value is NLT 70.0%.

6 ADDITIONAL REQUIREMENTS

Packaging and Storage: Preserve in tight containers. No storage requirements specied.

Labeling: Label it to indicate its nominal dextrose equivalent. Label it also to indicate the presence of sulfur dioxide if the residual

concentration is greater than 10 ppm (µg/g).

USP Reference Standards 〈11〉

USP Dextrose R
