Carbamazepine Tablets

This article is compiled based on the United States Pharmacopeia (USP) – 2025 Edition

Issued and maintained by the United States Pharmacopeial Convention (USP)

DOWNLOAD PDF HERE

To view the Notice from the Expert Committee that posted in conjunction with this accelerated revision, please click

1 DEFINITION

Carbamazepine Tablets contain NLT 92.0% and NMT 108.0% of the labeled amount of carbamazepine (C₁₅H₁₂N₂O).

2 IDENTIFICATION

A. SPECTROSCOPIC IDENTIFICATION TESTS (197), Infrared Spectroscopy: 197M

Sample solution: Nominally 250 mg of carbamazepine from powdered Tablets in 15 mL of acetone

Analysis: Boil the Sample solution for 5 min in a suitable beaker. Filter while hot, using two 5-mL portions of hot acetone to effect transfer.

Evaporate the filtrate with the aid of nitrogen to 5 mL, and cool in an ice bath until crystals are formed. Filter the crystals, wash with 3 mL of cold acetone, and dry under vacuum at 70° for 30 min. Use the crystals.

Acceptance criteria: Meet the requirements

B. The retention time of the major peak of the Sample solution corresponds to that of the Standard solution, as obtained in the Assay.

3 ASSAY

PROCEDURE

Mobile phase: Methanol, tetrahydrofuran, and water (12:3:85). Add 0.22 mL of formic acid and then 0.5 mL of triethylamine to each L.

Diluent: Methanol and water (50:50)

System suitability stock solution: 0.1 mg/mL of USP Carbamazepine RS and 0.5 mg/mL of USP Carbamazepine Related Compound A RS in methanol. Sonication may be used to aid in dissolution.

System suitability solution: 0.01 mg/mL of USP Carbamazepine RS and 0.05 mg/mL of USP Carbamazepine Related Compound A RS from System suitability stock solution in Diluent

Standard stock solution: 2 mg/mL of USP Carbamazepine RS in methanol. Sonication may be used to aid in dissolution.

Standard solution: 0.2 mg/mL of USP Carbamazepine RS from Standard stock solution in Diluent

Sample stock solution: Nominally 2 mg/mL of carbamazepine from NLT 20 Tablets prepared as follows. Finely powder the Tablets, and transfer a portion of the powder to a suitable volumetric flask. Add 80% of the final flask volume of methanol, sonicate for 15 min, and allow to cool to room temperature. Dilute with methanol to volume. Pass through a suitable filter and discard the first few mL of filtrate.

Sample solution: Nominally 0.2 mg/mL of carbamazepine from Sample stock solution in Diluent

Chromatographic system

(See Chromatography (621), System Suitability.)

Mode: LC

Detector: UV 230 nm

Column: 4.0- or 4.6-mm x 25-cm; 7-um packing L10

Flow rate: 1.5 mL/min

Injection volume: 20 µL

Run time: NLT 1.6 times the retention time of carbamazepine

System suitability

Samples: System suitability solution and Standard solution

[NOTE-See Table 3 for the relative retention times.]

Suitability requirements

Resolution: NLT 1.7 between carbamazepine related compound A and carbamazepine, System suitability solution

Relative standard deviation: NMT 2.0%, Standard solution

Analysis

Samples: Standard solution and Sample solution

Calculate the percentage of the labeled amount of carbamazepine (C₁₅H₁₂N₂O) in the portion of Tablets taken:

Result = (r_U/r_S) x (C_S/C_U) × 100

r_U = peak response from the Sample solution

r_S = peak response from the Standard solution

C_S = concentration of USP Carbamazepine RS in the Standard solution (mg/mL)

C_U = nominal concentration of carbamazepine in the Sample solution (mg/mL)

Acceptance criteria: 92.0%-108.0%

4 PERFORMANCE TESTS

Change to read:

DISSOLUTION (711)

For products labeled as 100-mg chewable Tablets

Test 1: if the product complies with this test, the labeling indicates that it meets USP Dissolution Test 1.

Medium: Water containing 1% sodium lauryl sulfate: 900 ml.

Apparatus 2: 75 rpm

Time: 60 min

Standard solution: USP Carbamazepine RS in Medium. [NOTE-A volume of methanol NMT 1% of the final total volume of the Standard solution may be used to dissolve the carbamazepine.]

Sample solution: Filtered portion of the solution under test, diluted with Medium if necessary

Instrumental conditions

Mode: UV

Analytical wavelength: Maximum absorbance at about 288 nm

Analysis

Samples: Standard solution and Sample solution

Calculate the percentage of the labeled amount of carbamazepine (C₁₅H₁₂N₂O) dissolved:

Result (A/A) xCxVx (1/L) x 100

A absorbance of the Sample solution

A absorbance of the Standard solution

C concentration of USP Carbamazepine RS in the Standard solution (mg/mL)

V volume of the Medium, 900 mL

L label claim (mg/Tablet)

Tolerances: NLT 75% (Q) of the labeled amount of carbamazepine (CH, NO) is dissolved. Use Dissolution (711), Acceptance Table 1 with the following exceptions: at S.,, no unit is less than 0-5%; at S, no unit is less than 0-10%; and NMT 2 of the 24 units are less than Q-5%.

For products labeled as 200-mg Tablets

Test 2: If the product complies with this test, the labeling indicates that it meets USP Dissolution Test 2.

Medium, Apparatus 2, Standard solution, Sample solution, and Instrumental conditions: Proceed as directed in Test 1.

Times: 15 and 60 min

Analysis

Calculate the concentration (C) of carbamazepine (C₁₅H₁₂N₂O) in the sample withdrawn from the vessel at each time point (1):

Result = (A_U/A_S) x C_S

A_U = absorbance of the Sample solution

A_S = absorbance of the Standard solution

C_S = concentration of USP Carbamazepine RS in the Standard solution (mg/mL)

Calculate the percentage of the labeled amount of carbamazepine (C₁₅H₁₂N₂O) dissolved at each time point (1):

Result₁ = C₁x Vx (1/L) x 100

Result₂ = [(CxV)+(C₁xV_S)]x (1/L) x 100

C_i = concentration of carbamazepine in the portion of sample withdrawn at the specified time point (1) (mg/ml.)

V = volume of the Mediurn, 900 mL

L = label claim (mg/Tablet) L = 1

V₂ = volume of the Medium at time point 2 (mL)

V_S = volume of the Sample solution withdrawn at each time point (i) (mL)

Tolerances: See Table 1.

Table 1

Use Dissolution (711). Accentance Table 2 with the following exceptions. At 15 min: at L ₂ unit is more than 5% outside the stated range; at L₃ no unit is more than 10% outside the stated range; and NMT 2 of the 24 units are more than 5% outside the stated range.

At 60 min: at L₂ no unit is less than Q - 5%; at L₃ unit is less than Q - 10% and NMT 2 of the 24 units are less than Q + (- 5)%

Test 3: If the product complies with this test, the labeling indicates that it meets USP Dissolution Test 3.

Medium, Apparatus 2, Standard solution, Sample solution, and Instrumental conditions: Proceed as indicated in Test 1.

Times: 15 and 60 min

Analysis

Samples: Standard solution and Sample solution

Calculate the concentration (C) of carbamazepine (C₁₅H₁₂N₂O) the sample withdrawn from the vessel at each time point (i): Result = (A_U/A_S) x C_S

A_U = absorbance of the Sample solution

A_S = absorbance of the Standard solution

C_S = concentration of USP Carbamazepine RS in the Standard solution (mg / m * L)

Calculate the percentage of the labeled amount of carbamazepine (C₁₅H₁₂N₂O) dissolved at each time point (1):

Result₁ = C₁ x V x (1/L) x 100

Result₂ = [(C₂xV₂) + (C₁xV_S) x (1/L) x 100

C_i = concentration of carbamazepine in the portion of sample withdrawn at the specified time point (i) (mg / m L)

v = volume of the Medium, 900 mL

L = label claim (mg/Tablet)

V₂ = volume of the Medium at time point 2 (mL)

V_S = volume of the Sample solution withdrawn at each time point (i) (mL)

Tolerances: See Table 2.

Table 2

Use Dissolution (711), Acceptance Table 2 with the following exceptions. At 15 min: at L₂ unit is more than 5% outside the stated range; at L₃ unit is more than 10% outside the stated range; and NMT 2 of the 24 units are more than 5% outside the stated range. At 60 min: L₂, no unit is less than Q + (- 5)% at L₃; no unit is less than Q - 10% and NMT 2 of the 24 units are less than Q + (- 5)%.

Test 4: If the product complies with this test, the labeling indicates that it meets USP Dissolution Test 4.

Medium: Water containing 1% sodium dodecyl sulfate: 900 mL

Apparatus 2: 75 rpm

Time: 45 min

Standard stock solution: 0.9 mg/mL of USP Carbamazepine RS in methanol. Sonicate to dissolve as needed.

Standard solution: 9 µg/mL of USP Carbamazepine RS from Standard stock solution in Medium

Sample solution: Pass a portion of the solution under test through a suitable filter of 0.45-um pore size and discard the first 3 mL of the filtrate. Dilute with Medium to a concentration similar to that of the Standard solution.

Instrumental conditions

(See Ultraviolet-Visible Spectroscopy (857).)

Mode: UV

Analytical wavelength: 288 nm

Cell length: 1 cm

Blank: Medium

Analysis

Samples: Standard solution and Sample solution

Calculate the percentage of the labeled amount of carbamazepine (C₁₅H₁₂N₂O) dissolved:

Result = (A_U/A_S) xC_SxDxVx (1/L)×100

A_U = absorbance of the Sample solution

A_S = absorbance of the Standard solution

C_S = concentration of USP Carbamazepine RS in the Standard solution (mg/mL)

D = dilution factor

V = volume of the Medium, 900 mL

L = label claim (mg/Tablet)

Tolerances: NLT 80% (Q) of the labeled amount of carbamazepine (C₁₅H₁₂N₂O) is dissolved. (RB 22-Sep-2022)

UNIFORMITY OF DOSAGE UNITS (905): Meet the requirements

5 IMPURITIES

ORGANIC IMPURITIES

Mobile phase, Diluent, and System suitability solution: Proceed as directed in the Assay.

Standard stock solution: 0.02 mg/mL each of USP Carbamazepine RS, USP Carbamazepine Related Compound B RS, and USP 9-Methylacridine RS in methanol. Sonication may be used to aid in dissolution.

Standard solution: 0.001 mg/mL each of USP Carbamazepine RS, USP Carbamazepine Related Compound B RS, and USP 9-Methylacridine

RS from Standard stock solution in Diluent

Sample solution: Nominally 1 mg/mL of carbamazepine from NLT 20 Tablets prepared as follows. Finely powder the Tablets, and transfer a portion of the powder to a suitable volumetric flask. Add about 50% of the final flask volume of Diluent, sonicate for 15 min, and allow to cool to room temperature. Dilute with Diluent to volume. Pass through a suitable filter and discard the first few mL of filtrate.

Chromatographic system: Proceed as directed in the Assay except use a Run time of NLT 3.5 times the retention time of carbamazepine.

System suitability

Samples: System suitability solution and Standard solution

[NOTE-See Table 3 for the relative retention times.]

Suitability requirements

Resolution: NLT 1.7 between carbamazepine related compound A and carbamazepine, System suitability solution

Relative standard deviation: NMT 10.0% each for carbamazepine, carbamazepine related compound B, and 9-methylacridine, Standard solution

Analysis

Samples: Standard solution and Sample solution

Calculate the percentage of carbamazepine related compound B and 9-methylacridine in the portion of Tablets taken.

Result = (r_U/r_S) x (C_S/C_U) × 100

r_U = peak response of carbamazepine related compound B or 9-methylacridine from the Sample solution

r_S = peak response of carbamazepine related compound 8 or 9-methylacridine from the Standard solution

C_S = concentration of USP Carbamazepine Related Compound B RS or USP 9-Methylacridine RS in the Standard solution (mg/mL)

C_U = nominal concentration of carbamazepine in the Sample solution (mg / m L)

Calculate the percentage of other degradation products in the portion of Tablets taken:

Result = (r_U/r_S) x (C_S/C_U) × 100

r_U = peak response of any individual unspecified degradation product from the Sample solution

r_S = peak response of carbamazepine from the Standard solution

C_S = concentration of USP Carbamazepine RS in the Standard solution (mg / m L)

C_U = nominal concentration of carbamazepine in the Sample solution (mg / mL)

Acceptance criteria: See Table 3. Disregard peaks below 0.05%.

Table 3

^a This is a process impurity that is controlled in the drug substance. It is not to be reported or included in the total degradation products.

6 ADDITIONAL REQUIREMENTS

PACKAGING AND STORAGE: Preserve in tight containers, preferably of glass. Protect from light and moisture. Store at controlled room temperature.

LABELING: The labeling indicates the Dissolution test with which the product complies.

USP REFERENCE STANDARDS (11).

USP Carbamazepine RS

USP Carbamazepine Related Compound A RS

10,11-Dihydrocarbamazepine.

C₁₅H₁₄N₂O   238.29

USP Carbamazepine Related Compound B RS

5H-Dibenz[b,flazepine.

C₁₄H₁₁N     193.25

USP 9-Methylacridine RS

9-Methylacridine.

C₁₄H₁₁N    193.25
